Identify the following image?

NORCET 5 Prelims - Sept 2023 (Shift-1)

Medical & Surgical Nursing

Hard

Appeared in: NORCET 5 Prelims - Sept 2023 (Shift-1)

Explanation

The image shows a surgically created opening (stoma) on the abdomen, which is made from a piece of intestinal tissue.
This procedure is known as an ileal conduit, a common type of urinary diversion.
A segment of the ileum (small intestine) is used to create a passageway for urine to exit the body after the bladder is removed or bypassed.
The two blue tubes visible are ureteral stents, which are temporarily placed to keep the ureters open and allow for proper healing of the ureter-to-ileum connection.
Urine drains continuously from this stoma into an external collection pouch.

Option A: A Bogotá bag is a temporary abdominal closure device. It is a sterile plastic bag sutured to the skin or fascia of the abdomen to cover exposed abdominal contents when the abdomen cannot be closed, such as in abdominal compartment syndrome. It does not involve a stoma for urinary diversion.
Option B: This refers to the use of a surgical mesh during a laparotomy (an open abdominal surgery). While a laparotomy is performed to create an ileal conduit, the primary object shown is the stoma itself, not a surgical mesh.
Option C: Hernioplasty is the surgical repair of a hernia, often using a mesh. The image does not show a hernia or its repair; it shows a stoma for urinary drainage.

Visual 1: Diagram - An anatomical illustration showing the urinary system after an ileal conduit procedure. It would depict the kidneys, ureters connected to the isolated ileal segment, and the stoma on the abdominal wall. This helps visualize the new path of urine flow.
Visual 2: Photograph - A series of photos showing a healthy stoma, a retracted stoma, and a prolapsed stoma to help students learn to assess for complications.

Clinical Relevance

Nursing practice connection: This is primarily an exam-oriented knowledge point with limited direct bedside application, so retain Identification of surgical stomas and urinary diversion procedures as background academic context rather than a clinical decision trigger.
Postoperative nursing care for a patient with a new ileal conduit is critical. Nurses must monitor the stoma for color, size, and viability. A healthy stoma should be pink or red and moist. A dark red, purple, or black stoma indicates compromised blood supply and is a surgical emergency.
Nurses are responsible for stoma and peristomal skin care, teaching the patient how to manage the ostomy appliance, and monitoring urine output. Urine from an ileal conduit will contain mucus shreds from the intestinal segment, which is a normal finding.
What if? - If the ureteral stents were not present in the image, it would likely indicate that the patient is further along in their postoperative recovery, as stents are typically removed a few weeks after surgery.

How to Approach the Question

First, carefully examine the image to identify its key features. Note the presence of a round, reddish opening on the skin, which is a stoma.
Observe the two thin, blue tubes coming out of the stoma. Recognize these as catheters or stents.
Consider the location on the abdomen and the nature of the stoma (made of intestinal tissue). This points towards a procedure involving the gastrointestinal or urinary tract.
Evaluate the options. 'Bagota bag', 'Mesh with laparotomy', and 'Mesh with hernioplasty' describe different surgical materials or procedures that do not match the visual evidence of a stoma with stents.
The term 'Ileal conduit' describes a urinary diversion using a segment of the ileum, which results in a stoma exactly like the one pictured. The presence of ureteral stents further confirms this identification.
Therefore, conclude that the image depicts an ileal conduit.

Concept Tested & Keywords

Concept Tested: Identification of surgical stomas and urinary diversion procedures.
Stem keywords: Identify, image
Lead-in keywords: BEST, MOST RELEVANT CLUE
Clinical cues: Presence of a surgically created stoma on the abdomen.
Clinical cues: Two blue tubes (ureteral stents) emerging from the stoma.
